transit
- transit.draw_transit(planet_to_star_ratio, planet_physical_radius, impact_parameter=0.0, phase=0.0, grid_size=100, supersampling=None, resample_method=None, limb_darkening_law=None, ld_coefficient=None)[source]
Calculate a normalized transit map. Additionally, calculate two-dimensional arrays of density and line-of-sight radial velocities around the planet.
- Parameters
- planet_to_star_ratio (``float``):
Ratio between the radii of the planet and the star.
- planet_physical_radius (``float``):
Physical radius of the planet in whatever unit you want to work with.
- impact_parameter (``float``, optional):
Transit impact parameter of the planet (not the atmosphere). Default is 0.0.
- phase (``float``, optional):
Phase of the transit. -0.5, 0.0, and +0.5 correspond to the center of planet being located at, respectively, the left limb of the star, the center, and the right limb. Default is 0.0.
- grid_size (``int``, optional):
Size of the transit grid. Default is 100.
- supersampling (``float`` or ``None``, optional):
In order to avoid pixels with hard edges, it is useful to first compute the transit grid at a high resolution and then downscale it to a manageable grid size. Supersampling is the factor by which to increase the grid size at first and then downscale to the requested grid size. If
None
, no supersampling is applied. Default isNone
.- resample_method (``str`` or ``None``, optional):
Method by which to resample the image if supersampling is used. If
None
, then fallback to a “box” method. Available methods are"nearest"
,"box"
,"bilinear"
,"hamming"
and"lanczos"
(the last two are not recommended for research-grade results. Default isNone
.- limb_darkening_law (``None`` or ``str``, optional):
String with the name of the limb-darkening law. The options are the same currently implemented in the code
flatstar
:'linear'
,'quadratic'
,'square-root'
,'log'
,'exp'
,'s3'
,'c4'
, orNone
(no limb-darkening). Default isNone
.- ld_coefficient (``float`` or ``array-like``):
In case of a linear limb-darkening law, the value of the coefficient should be a float. In all other options it should be array-like. Default is
None
.
- Returns
- normalized_intensity_map (
numpy.ndarray
): 2-D map of intensity normalized in such a way that the sum of the array will be 1.0 if the planet is not transiting.
- transit_depth (
float
): Absorption caused by the opaque disk of the planet in the specified transit configuration.
- r_from_planet (
numpy.ndarray
): 2-D map of radial distances of each pixel from the center of the planet in the same unit as
planet_physical_radius
.
- normalized_intensity_map (
- transit.radiative_transfer_2d(intensity_0, r_from_planet, radius_profile, density_profile, velocity_profile, central_wavelength, oscillator_strength, einstein_coefficient, wavelength_grid, gas_temperature, particle_mass, bulk_los_velocity=0.0, wind_broadening_method='average', turbulence_broadening=False)[source]
Calculate the absorbed intensity profile in a wavelength grid.
- Parameters
- intensity_0 (``float`` or ``numpy.ndarray``):
Original flux intensity originating from a background illuminating source. If
numpy.ndarray
, must have the same shape asr_from_planet
.- r_from_planet (``numpy.ndarray``):
2-D map of radial distances of each pixel from the center of the planet. The unit has to be consistent with the other input parameters. E.g., if you use unit of meters, all other input parameters with length in the unit also have to be in meters.
- radius_profile (``numpy.ndarray``):
1-D profile of radii in which the densities are sampled. Unit has to be the same as
r_from_planet
.- density_profile (``numpy.ndarray``):
1-D profile of volumetric number densities in function of radius. Unit has to be 1 / length ** 3, where length is the same unit as
r_from_planet
.- velocity_profile (``numpy.ndarray``):
1-D profile of velocities in function of radius. Unit has to be m / s.
- central_wavelength (``float`` or ``array_like``):
Central wavelength of the transition in unit of m. If more than one line is to be calculated, then input this parameter as an array-like object.
- oscillator_strength (``float``):
Oscillator strength of the transition. The format or shape of this input parameter needs to be consistent with that of
central_wavelength
.- einstein_coefficient (``float``):
Einstein coefficient of the transition in 1 / s. The format or shape of this input parameter needs to be consistent with that of
central_wavelength
.- wavelength_grid (``numpy.ndarray``):
Wavelengths to calculate the profile in unit of m.
- gas_temperature (``float``):
Gas temperature in K.
- particle_mass (``float``):
Mass of the particle corresponding to the transition in unit of kg.
- bulk_los_velocity (``float``, optional):
Bulk velocity of the gas cell in the line of sight in unit of m / s. Default is 0.0.
- wind_broadening_method (``str``, optional):
Method of calculation for the wind broadening. There are two options: 1)
'formal'
: the formal definition of radiative transfer taking into account the full dimensionality of the wind (slower); 2)'average'
: assumes the Parker wind broadening contributes to the Gaussian term of the Voigt profile with an additive factor proportional to the square of the density-averaged, line-of-sight velocity (faster).- turbulence_broadening (``bool``, optional):
If
True
, adds a turbulence broadening, defined as in Lampón et al. 2020, to the Gaussian term of the Voigt profile. Default isFalse
.
- Returns
- intensity (
numpy.ndarray
): Absorbed intensity profile in function of
wavelength_grid
.
- intensity (
- transit.profile_los(radius_profile, density_profile, velocity_profile, z_grid_size=200)[source]
Calculate the profiles of radius and line-of-sight velocities in function of sky-projected radial distance from the planet (axis 0) and the line of sight direction (axis 1).
- Parameters
- radius_profile (``numpy.ndarray``):
1-D profile of radii in which the densities are sampled, in whatever unit you want to work with.
- density_profile (``numpy.ndarray``):
1-D profile of volumetric number densities in function of radius, in whatever unit you want to work with.
- velocity_profile (``numpy.ndarray``):
1-D profile of velocities in function of radius, in whatever unit you want to work with.
- Returns
- los_density_r_z (
numpy.ndarray
): 2-D map of densities in the x- and z-axis distances from the center of the planet.
- los_velocity_r_z (
numpy.ndarray
): 2-D map of line-of-sight velocities in the x- and z-axis distances from the center of the planet.
- los_density_r_z (
- transit.optical_depth_2d(radius_profile, density_profile, velocity_profile, central_wavelength, oscillator_strength, einstein_coefficient, wavelength_grid, gas_temperature, particle_mass, bulk_los_velocity=0.0, wind_broadening_method='average', turbulence_broadening=False)[source]
Calculate the optical depth in function of cylindrical radius from the planet and the wavelength.
- Parameters
- radius_profile (``numpy.ndarray``):
1-D profile of radii in which the densities are sampled. Unit has to be consistent with the other input parameters involving lenghts and densities.
- density_profile (``numpy.ndarray``):
1-D profile of volumetric number densities in function of radius. Unit has to be 1 / length ** 3, where length is the same unit as
radius_profile
.- velocity_profile (``numpy.ndarray``):
1-D profile of velocities in function of radius. Unit has to be m / s.
- central_wavelength (``float`` or ``array_like``):
Central wavelength of the transition in unit of m. If more than one line is to be calculated, then input this parameter as an array-like object.
- oscillator_strength (``float``):
Oscillator strength of the transition. The format or shape of this input parameter needs to be consistent with that of
central_wavelength
.- einstein_coefficient (``float``):
Einstein coefficient of the transition in 1 / s. The format or shape of this input parameter needs to be consistent with that of
central_wavelength
.- wavelength_grid (``numpy.ndarray``):
Wavelengths to calculate the profile in unit of m.
- gas_temperature (``float``):
Gas temperature in K.
- particle_mass (``float``):
Mass of the particle corresponding to the transition in unit of kg.
- bulk_los_velocity (``float``, optional):
Bulk velocity of the gas cell in the line of sight in unit of m / s. Default is 0.0.
- wind_broadening_method (``str``, optional):
Method of calculation for the wind broadening. There are two options: 1)
'formal'
: the formal definition of radiative transfer taking into account the full dimensionality of the wind (slower); 2)'average'
: assumes the Parker wind broadening contributes to the Gaussian term of the Voigt profile with an additive factor proportional to the square of the density-averaged, line-of-sight velocity (faster).- turbulence_broadening (``bool``, optional):
If
True
, adds a turbulence broadening, defined as in Lampón et al. 2020, to the Gaussian term of the Voigt profile. Only used ifwind_broadening_method
is set to'average'
. Default isFalse
.
- Returns
- optical_depth_array (
numpy.ndarray
): Optical depth in function of radial distance from the center of the planet (axis 0) and in function of wavelength (axis 1).
- optical_depth_array (
